UPM1H271MHD6TN
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 270UF 20% 50V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UPM1H271MHD6TN Datasheet
-
ECAD Model
- Share
In Stock: 595
Can ship immediately
Pricing:
- 1$1.22
- 250$0.54643
- 500$0.46835
- 750$0.42932
- 1,250$0.4033
- 2,500$0.37729
- 6,250$0.35776
- 12,500$0.33903
- 25,000$0.33176
Quote It
Technical Details
- Series:UPM
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:270 µF
- Tolerance:±20%
- Voltage - Rated:50 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:840 mA @ 120 Hz
- Ripple Current @ High Frequency:1.12 A @ 10 kHz
- Impedance:70 mOhms
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):0.669" (17.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
