UCY2D820MHD1TO
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 82UF 20% 200V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UCY2D820MHD1TO Datasheet
-
ECAD Model
- Share
In Stock: 877
Can ship immediately
Pricing:
- 1$1.65
- 500$0.61157
- 1,000$0.53961
- 2,500$0.50364
- 5,000$0.48566
- 12,500$0.45867
Quote It
Technical Details
- Series:UCY
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:82 µF
- Tolerance:±20%
- Voltage - Rated:200 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:12000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:645 mA @ 120 Hz
- Ripple Current @ High Frequency:1.29 A @ 100 kHz
- Impedance:-
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.492" Dia (12.50mm)
- Height - Seated (Max):1.043" (26.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
