UHV1A272MHD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 2700UF 20% 10V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UHV1A272MHD Datasheet
-
ECAD Model
- Share
In Stock: 656
Can ship immediately
Pricing:
- 1$0.97
- 10$0.7379
- 100$0.52784
- 500$0.40864
- 1,000$0.35189
- 2,500$0.32919
- 5,000$0.31217
Quote It
Technical Details
- Series:UHV
- Package:Bulk
- Part Status:Active
- Capacitance:2700 µF
- Tolerance:±20%
- Voltage - Rated:10 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:6000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:-
- Ripple Current @ High Frequency:2.475 A @ 100 kHz
- Impedance:16 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.492" Dia (12.50mm)
- Height - Seated (Max):0.866" (22.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
