UHD0J392MHD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 3900UF 20% 6.3V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UHD0J392MHD Datasheet
-
ECAD Model
- Share
In Stock: 627
Can ship immediately
Pricing:
- 1$1.03
- 10$0.78166
- 100$0.55883
- 500$0.4326
- 1,000$0.37252
- 2,500$0.34848
- 5,000$0.33045
Quote It
Technical Details
- Series:UHD
- Package:Bulk
- Part Status:Active
- Capacitance:3900 µF
- Tolerance:±20%
- Voltage - Rated:6.3 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:2.216 A @ 120 Hz
- Ripple Current @ High Frequency:2.77 A @ 100 kHz
- Impedance:18 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.492" Dia (12.50mm)
- Height - Seated (Max):1.063" (27.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
