50SEV330M12.5X13.5
Rubycon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 330UF 20% 50V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet 50SEV330M12.5X13.5 Datasheet
-
ECAD Model
- Share
In Stock: 434
Can ship immediately
Pricing:
- 1$1.76
- 200$0.94478
- 400$0.8398
- 600$0.71382
- 1,000$0.62985
- 2,000$0.58786
- 5,000$0.56687
- 10,000$0.54587
Quote It
Technical Details
- Series:SEV
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:330 µF
- Tolerance:±20%
- Voltage - Rated:50 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:600 mA @ 120 Hz
- Ripple Current @ High Frequency:720 mA @ 10 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.492" Dia (12.50mm)
- Height - Seated (Max):0.551" (14.00mm)
- Surface Mount Land Size:0.512" L x 0.512" W (13.00mm x 13.00mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
