UCYW6270MHD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 27UF 20% 420V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UCYW6270MHD Datasheet
-
ECAD Model
- Share
In Stock: 390
Can ship immediately
Pricing:
- 1$1.97
- 10$1.55058
- 100$1.16281
- 500$0.8786
- 1,000$0.77523
- 2,500$0.72353
- 5,000$0.69769
Quote It
Technical Details
- Series:UCY
- Package:Bulk
- Part Status:Active
- Capacitance:27 µF
- Tolerance:±20%
- Voltage - Rated:420 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:12000 Hrs @ 105°C
- Operating Temperature:-25°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:340 mA @ 120 Hz
- Ripple Current @ High Frequency:680 mA @ 100 kHz
- Impedance:-
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.492" Dia (12.50mm)
- Height - Seated (Max):0.846" (21.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
