25SEV3300M18X21.5
Rubycon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 3300UF 20% 25V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet 25SEV3300M18X21.5 Datasheet
-
ECAD Model
- Share
In Stock: 329
Can ship immediately
Pricing:
- 1$3.51
- 75$3.51
- 150$3.07123
- 375$2.63246
- 525$2.33995
- 750$2.1937
- 1,875$2.04745
- 3,750$1.97434
- 7,500$1.90121
Quote It
Technical Details
- Series:SEV
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:3300 µF
- Tolerance:±20%
- Voltage - Rated:25 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:1.7 A @ 120 Hz
- Ripple Current @ High Frequency:1.955 A @ 10 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.709" Dia (18.00mm)
- Height - Seated (Max):0.866" (22.00mm)
- Surface Mount Land Size:0.748" L x 0.748" W (19.00mm x 19.00mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
