LAQ2D181MELZ25
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 180UF 20% 200V SNAP
- CategoryAluminum Electrolytic Capacitors
- Datasheet LAQ2D181MELZ25 Datasheet
-
ECAD Model
- Share
In Stock: 285
Can ship immediately
Pricing:
- 1$3.56
- 10$2.86829
- 100$2.23713
- 500$1.66349
- 1,000$1.56024
Quote It
Technical Details
- Series:LAQ
- Package:Bulk
- Part Status:Active
- Capacitance:180 µF
- Tolerance:±20%
- Voltage - Rated:200 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 105°C
- Operating Temperature:-25°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:700 mA @ 120 Hz
- Ripple Current @ High Frequency:840 mA @ 10 kHz
- Impedance:-
- Lead Spacing:0.394" (10.00mm)
- Size / Dimension:0.866" Dia (22.00mm)
- Height - Seated (Max):1.063" (27.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can - Snap-In
