UPS2C331MRD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 330UF 20% 160V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UPS2C331MRD Datasheet
-
ECAD Model
- Share
In Stock: 253
Can ship immediately
Pricing:
- 1$3.79
- 10$3.07003
- 100$2.34435
- 500$1.78614
- 1,000$1.56287
- 2,500$1.50705
- 5,000$1.45125
Quote It
Technical Details
- Series:UPS
- Package:Bulk
- Part Status:Active
- Capacitance:330 µF
- Tolerance:±20%
- Voltage - Rated:160 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:3000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:900 mA @ 120 Hz
- Ripple Current @ High Frequency:1.035 A @ 10 kHz
- Impedance:-
- Lead Spacing:0.394" (10.00mm)
- Size / Dimension:0.787" Dia (20.00mm)
- Height - Seated (Max):1.654" (42.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
