EEE-FK0J271SP
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 270UF 20% 6.3V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEE-FK0J271SP Datasheet
-
ECAD Model
- Share
In Stock: 332
Can ship immediately
Pricing:
- 1$0.53
- 1,000$0.14859
- 2,000$0.13985
- 5,000$0.13111
- 10,000$0.12237
- 25,000$0.11799
- 50,000$0.11363
Quote It
Technical Details
- Series:FKS
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:270 µF
- Tolerance:±20%
- Voltage - Rated:6.3 V
- ESR (Equivalent Series Resistance):360mOhm @ 100kHz
- Lifetime @ Temp.:2000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:156 mA @ 120 Hz
- Ripple Current @ High Frequency:240 mA @ 100 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.248" Dia (6.30mm)
- Height - Seated (Max):0.240" (6.10mm)
- Surface Mount Land Size:0.260" L x 0.260" W (6.60mm x 6.60mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
