EEE-HC0J221XP
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 220UF 20% 6.3V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEE-HC0J221XP Datasheet
-
ECAD Model
- Share
In Stock: 1,124
Can ship immediately
Pricing:
- 1$0.54
- 900$0.15216
- 1,800$0.1437
- 2,700$0.13525
- 4,500$0.1268
- 9,000$0.11834
- 22,500$0.11622
- 45,000$0.11496
Quote It
Technical Details
- Series:HC
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:220 µF
- Tolerance:±20%
- Voltage - Rated:6.3 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:3000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:101 mA @ 120 Hz
- Ripple Current @ High Frequency:171.7 mA @ 10 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.248" Dia (6.30mm)
- Height - Seated (Max):0.303" (7.70mm)
- Surface Mount Land Size:0.260" L x 0.260" W (6.60mm x 6.60mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
