EEU-FM1V221B
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 220UF 20% 35V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEU-FM1V221B Datasheet
-
ECAD Model
- Share
In Stock: 958
Can ship immediately
Pricing:
- 1$0.56
- 500$0.17603
- 1,000$0.14963
- 2,500$0.14082
- 5,000$0.13202
- 12,500$0.12102
- 25,000$0.1197
Quote It
Technical Details
- Series:FM
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:220 µF
- Tolerance:±20%
- Voltage - Rated:35 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:4000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:903 mA @ 120 Hz
- Ripple Current @ High Frequency:1.29 A @ 100 kHz
- Impedance:38 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.551" (14.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
