UKT1H101MPD1TD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 100UF 20% 50V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UKT1H101MPD1TD Datasheet
-
ECAD Model
- Share
In Stock: 729
Can ship immediately
Pricing:
- 1$0.69
- 1,000$0.16689
- 2,000$0.15707
- 5,000$0.14725
- 10,000$0.13744
- 25,000$0.13253
- 50,000$0.12762
Quote It
Technical Details
- Series:UKT
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:100 µF
- Tolerance:±20%
- Voltage - Rated:50 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:1000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:-
- Ratings:-
- Applications:Audio
- Ripple Current @ Low Frequency:190 mA @ 120 Hz
- Ripple Current @ High Frequency:285 mA @ 10 kHz
- Impedance:-
- Lead Spacing:0.138" (3.50mm)
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.492" (12.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
