UZT1C470MCL1GB
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 47UF 20% 16V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet UZT1C470MCL1GB Datasheet
-
ECAD Model
- Share
In Stock: 687
Can ship immediately
Pricing:
- 1$0.8
- 1,000$0.21456
- 2,000$0.20194
- 5,000$0.18932
- 10,000$0.17669
- 25,000$0.17039
- 50,000$0.16407
Quote It
Technical Details
- Series:UZT
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:47 µF
- Tolerance:±20%
- Voltage - Rated:16 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:1000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:-
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:44 mA @ 120 Hz
- Ripple Current @ High Frequency:66 mA @ 10 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.248" Dia (6.30mm)
- Height - Seated (Max):0.181" (4.60mm)
- Surface Mount Land Size:0.260" L x 0.260" W (6.60mm x 6.60mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
