UPM1H101MPD6TD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 100UF 20% 50V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UPM1H101MPD6TD Datasheet
-
ECAD Model
- Share
In Stock: 507
Can ship immediately
Pricing:
- 1$0.8
- 500$0.25158
- 1,000$0.21384
- 2,500$0.20126
- 5,000$0.18868
- 12,500$0.17296
- 25,000$0.16982
- 50,000$0.16353
Quote It
Technical Details
- Series:UPM
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:100 µF
- Tolerance:±20%
- Voltage - Rated:50 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:385 mA @ 120 Hz
- Ripple Current @ High Frequency:580 mA @ 10 kHz
- Impedance:160 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.669" (17.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
