RTK-35V101MH11GU-RRD
Elna America
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 100UF 20% 35V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet RTK-35V101MH11GU-RRD Datasheet
-
ECAD Model
- Share
In Stock: 393
Can ship immediately
Pricing:
- 1$1.12
- 400$0.5364
- 800$0.42913
- 1,200$0.4023
- 2,000$0.37548
- 4,000$0.36207
- 10,000$0.34866
- 20,000$0.34196
Quote It
Technical Details
- Series:RTK
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Obsolete
- Capacitance:100 µF
- Tolerance:±20%
- Voltage - Rated:35 V
- ESR (Equivalent Series Resistance):3.3Ohm @ 120Hz
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 125°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:78.54 mA @ 120 Hz
- Ripple Current @ High Frequency:102 mA @ 100 kHz
- Impedance:550 mOhms
- Lead Spacing:-
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.433" (11.00mm)
- Surface Mount Land Size:0.409" L x 0.409" W (10.40mm x 10.40mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
