UHE1J471MHD6TN
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 470UF 20% 63V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UHE1J471MHD6TN Datasheet
-
ECAD Model
- Share
In Stock: 435
Can ship immediately
Pricing:
- 1$1.19
- 250$0.56974
- 500$0.48429
- 750$0.45579
- 1,250$0.4273
- 2,500$0.39882
- 6,250$0.38742
Quote It
Technical Details
- Series:UHE
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:470 µF
- Tolerance:±20%
- Voltage - Rated:63 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:10000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:847.5 mA @ 120 Hz
- Ripple Current @ High Frequency:1.13 A @ 100 kHz
- Impedance:91 mOhms
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):0.866" (22.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
