UPW1J681MHD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 680UF 20% 63V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UPW1J681MHD Datasheet
-
ECAD Model
- Share
In Stock: 129
Can ship immediately
Pricing:
- 1$1.35
- 10$1.0617
- 100$0.7965
- 500$0.60175
- 1,000$0.53096
- 2,500$0.49557
- 5,000$0.48141
Quote It
Technical Details
- Series:UPW
- Package:Bulk
- Part Status:Active
- Capacitance:680 µF
- Tolerance:±20%
- Voltage - Rated:63 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:8000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.62 A @ 120 Hz
- Ripple Current @ High Frequency:2.16 A @ 100 kHz
- Impedance:50 mOhms
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):0.984" (25.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
