EEU-FC1E332S
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 3300UF 20% 25V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEU-FC1E332S Datasheet
-
ECAD Model
- Share
In Stock: 228
Can ship immediately
Pricing:
- 1$2.18
- 10$1.71991
- 100$1.29033
- 500$0.97488
- 1,000$0.86018
- 2,500$0.80283
- 5,000$0.77416
Quote It
Technical Details
- Series:FC
- Package:Bulk
- Part Status:Active
- Capacitance:3300 µF
- Tolerance:±20%
- Voltage - Rated:25 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:2.329 A @ 120 Hz
- Ripple Current @ High Frequency:2.74 A @ 100 kHz
- Impedance:20 mOhms
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.709" Dia (18.00mm)
- Height - Seated (Max):0.984" (25.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
