EEU-FC1V151B
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 150UF 20% 35V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEU-FC1V151B Datasheet
-
ECAD Model
- Share
In Stock: 151
Can ship immediately
Pricing:
- 1$0.53
- 1,000$0.12829
- 2,000$0.12154
- 5,000$0.11479
- 10,000$0.10804
- 25,000$0.10128
- 50,000$0.09453
- 100,000$0.08778
Quote It
Technical Details
- Series:FC
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:150 µF
- Tolerance:±20%
- Voltage - Rated:35 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:360.8 mA @ 120 Hz
- Ripple Current @ High Frequency:555 mA @ 100 kHz
- Impedance:117 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.492" (12.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
