UVR0J472MHD1TO
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 4700UF 20% 6.3V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UVR0J472MHD1TO Datasheet
-
ECAD Model
- Share
In Stock: 152
Can ship immediately
Pricing:
- 1$0.82
- 500$0.27106
- 1,000$0.22825
- 2,500$0.21399
- 5,000$0.19972
- 12,500$0.18974
- 25,000$0.18546
- 50,000$0.18189
Quote It
Technical Details
- Series:UVR
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:4700 µF
- Tolerance:±20%
- Voltage - Rated:6.3 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.55 A @ 120 Hz
- Ripple Current @ High Frequency:1.7825 A @ 10 kHz
- Impedance:-
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.492" Dia (12.50mm)
- Height - Seated (Max):0.866" (22.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
