UCY2C680MHD3TO
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 68UF 20% 160V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UCY2C680MHD3TO Datasheet
-
ECAD Model
- Share
In Stock: 164
Can ship immediately
Pricing:
- 1$1.19
- 500$0.46466
- 1,000$0.40013
- 2,500$0.37431
- 5,000$0.35495
- 12,500$0.33636
- 25,000$0.32914
Quote It
Technical Details
- Series:UCY
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:68 µF
- Tolerance:±20%
- Voltage - Rated:160 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:12000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:590 mA @ 120 Hz
- Ripple Current @ High Frequency:1.18 A @ 100 kHz
- Impedance:-
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.492" Dia (12.50mm)
- Height - Seated (Max):0.846" (21.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
