ESG226M250AL3AA
KEMET
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 22UF 20% 250V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet ESG226M250AL3AA Datasheet
-
ECAD Model
- Share
In Stock: 2,137
Can ship immediately
Pricing:
- 1$0.71
- 10$0.52334
- 100$0.35924
- 500$0.28439
- 1,000$0.23948
- 2,500$0.22451
- 5,000$0.20954
Quote It
Technical Details
- Series:ESG
- Package:Bulk
- Part Status:Active
- Capacitance:22 µF
- Tolerance:±20%
- Voltage - Rated:250 V
- ESR (Equivalent Series Resistance):2.5Ohm @ 100kHz
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:160 mA @ 120 Hz
- Ripple Current @ High Frequency:256 mA @ 10 kHz
- Impedance:2.5 Ohms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.512" Dia (13.00mm)
- Height - Seated (Max):0.866" (22.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
