EEU-FS2A391B
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 390UF 20% 100V THRUHOLE
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEU-FS2A391B Datasheet
-
ECAD Model
- Share
In Stock: 177
Can ship immediately
Pricing:
- 1$2.16
- 250$1.04129
- 500$0.92557
- 750$0.86772
- 1,250$0.80987
- 2,500$0.78096
- 6,250$0.75203
- 12,500$0.7231
Quote It
Technical Details
- Series:FS
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:390 µF
- Tolerance:±20%
- Voltage - Rated:100 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:10000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.875 A @ 120 Hz
- Ripple Current @ High Frequency:2.5 A @ 100 kHz
- Impedance:25 mOhms
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):1.063" (27.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
