25TRV2200M18X16.5
Rubycon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 2200UF 20% 25V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet 25TRV2200M18X16.5 Datasheet
-
ECAD Model
- Share
In Stock: 152
Can ship immediately
Pricing:
- 1$3.13
- 125$1.76042
- 250$1.50893
- 625$1.34127
- 875$1.25744
- 1,250$1.17361
- 3,125$1.1317
- 6,250$1.08978
Quote It
Technical Details
- Series:TRV
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:2200 µF
- Tolerance:±20%
- Voltage - Rated:25 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:10000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:930 mA @ 120 Hz
- Ripple Current @ High Frequency:1.55 A @ 100 kHz
- Impedance:64 mOhms
- Lead Spacing:-
- Size / Dimension:0.709" Dia (18.00mm)
- Height - Seated (Max):0.669" (17.00mm)
- Surface Mount Land Size:0.748" L x 0.748" W (19.00mm x 19.00mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
