UPJ2A330MPD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 33UF 20% 100V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UPJ2A330MPD Datasheet
-
ECAD Model
- Share
In Stock: 228
Can ship immediately
Pricing:
- 1$0.52
- 10$0.36631
- 100$0.24116
- 500$0.17865
- 1,000$0.15185
- 2,500$0.14292
- 5,000$0.13399
Quote It
Technical Details
- Series:UPJ
- Package:Bulk
- Part Status:Active
- Capacitance:33 µF
- Tolerance:±20%
- Voltage - Rated:100 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:3000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:169 mA @ 120 Hz
- Ripple Current @ High Frequency:299 mA @ 10 kHz
- Impedance:380 mOhms
- Lead Spacing:0.138" (3.50mm)
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.630" (16.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
