UCY2E820MHD9
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 82UF 20% 250V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UCY2E820MHD9 Datasheet
-
ECAD Model
- Share
In Stock: 148
Can ship immediately
Pricing:
- 1$1.96
- 10$1.54278
- 100$1.1572
- 500$0.87432
- 1,000$0.77145
- 2,500$0.72002
- 5,000$0.69431
Quote It
Technical Details
- Series:UCY
- Package:Bulk
- Part Status:Active
- Capacitance:82 µF
- Tolerance:±20%
- Voltage - Rated:250 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:12000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:615 mA @ 120 Hz
- Ripple Current @ High Frequency:1.23 A @ 100 kHz
- Impedance:-
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.492" Dia (12.50mm)
- Height - Seated (Max):1.043" (26.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
