UCX1H102MNS1MS
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 1000UF 20% 50V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet UCX1H102MNS1MS Datasheet
-
ECAD Model
- Share
In Stock: 147
Can ship immediately
Pricing:
- 1$3.34
- 75$2.145
- 150$1.87682
- 375$1.60873
- 525$1.42997
- 750$1.34061
- 1,875$1.25123
- 3,750$1.20655
- 7,500$1.16186
Quote It
Technical Details
- Series:UCX
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:1000 µF
- Tolerance:±20%
- Voltage - Rated:50 V
- ESR (Equivalent Series Resistance):50mOhm
- Lifetime @ Temp.:2000 Hrs @ 135°C
- Operating Temperature:-40°C ~ 135°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:800 mA @ 120 Hz
- Ripple Current @ High Frequency:1.6 A @ 100 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):0.866" (22.00mm)
- Surface Mount Land Size:0.673" L x 0.673" W (17.10mm x 17.10mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
