LQR2V682MSEH
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 6800UF 20% 350V SCREW
- CategoryAluminum Electrolytic Capacitors
- Datasheet LQR2V682MSEH Datasheet
-
ECAD Model
- Share
In Stock: 183
Can ship immediately
Pricing:
- 1$89.72
- 10$84.10896
- 100$72.89485
Quote It
Technical Details
- Series:LQR
- Package:Bulk
- Part Status:Active
- Capacitance:6800 µF
- Tolerance:±20%
- Voltage - Rated:350 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 85°C
- Operating Temperature:-25°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:22.9 A @ 120 Hz
- Ripple Current @ High Frequency:32.06 A @ 10 kHz
- Impedance:-
- Lead Spacing:1.252" (31.80mm)
- Size / Dimension:3.000" Dia (76.20mm)
- Height - Seated (Max):5.236" (133.00mm)
- Surface Mount Land Size:-
- Mounting Type:Chassis Mount
- Package / Case:Radial, Can - Screw Terminals
