400BXC2R2MEFC8X11.5
Rubycon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM RAD
- CategoryAluminum Electrolytic Capacitors
- Datasheet 400BXC2R2MEFC8X11.5 Datasheet
-
ECAD Model
- Share
In Stock: 118
Can ship immediately
Pricing:
- 1$0.1472
- 2,000$0.14051
Quote It
Technical Details
- Series:BXC
- Package:Bulk
- Part Status:Active
- Capacitance:2.2 µF
- Tolerance:±20%
- Voltage - Rated:400 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:8000 Hrs @ 105°C
- Operating Temperature:-25°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:19 mA @ 120 Hz
- Ripple Current @ High Frequency:95 mA @ 100 kHz
- Impedance:-
- Lead Spacing:0.138" (3.50mm)
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.531" (13.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
