UPM1A561MPD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 560UF 20% 10V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UPM1A561MPD Datasheet
-
ECAD Model
- Share
In Stock: 1,343
Can ship immediately
Pricing:
- 1$0.20039
- 10$0.14265
- 100$0.09401
- 500$0.06963
- 1,000$0.05918
- 2,500$0.0557
- 5,000$0.05222
Quote It
Technical Details
- Series:UPM
- Package:Bulk
- Part Status:Active
- Capacitance:560 µF
- Tolerance:±20%
- Voltage - Rated:10 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:3000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:595 mA @ 120 Hz
- Ripple Current @ High Frequency:730 mA @ 10 kHz
- Impedance:100 mOhms
- Lead Spacing:0.138" (3.50mm)
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.846" (21.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
