ATB337M016
Cornell Dubilier Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 330UF 20% 16V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet ATB337M016 Datasheet
-
ECAD Model
- Share
In Stock: 4,131
Can ship immediately
Pricing:
- 1$0.20355
Quote It
Technical Details
- Series:ATB
- Package:Bulk
- Part Status:Active
- Capacitance:330 µF
- Tolerance:±20%
- Voltage - Rated:16 V
- ESR (Equivalent Series Resistance):760mOhm @ 120Hz
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:Bypass, Decoupling
- Ripple Current @ Low Frequency:420 mA @ 120 Hz
- Ripple Current @ High Frequency:600 mA @ 100 kHz
- Impedance:160 mOhms
- Lead Spacing:-
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.413" (10.50mm)
- Surface Mount Land Size:0.327" L x 0.339" W (8.30mm x 8.60mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
