UCX1H471MNQ1ZD

Technical Details

• Series:UCX
• Package:Tray
• Part Status:Active
• Capacitance:470 µF
• Tolerance:±20%
• Voltage - Rated:50 V
• ESR (Equivalent Series Resistance):70mOhm @ 100kHz
• Lifetime @ Temp.:2000 Hrs @ 135°C
• Operating Temperature:-40°C ~ 135°C
• Polarization:Polar
• Ratings:-

• Applications:General Purpose
• Ripple Current @ Low Frequency:500 mA @ 120 Hz
• Ripple Current @ High Frequency:1 A @ 100 kHz
• Impedance:-
• Lead Spacing:-
• Size / Dimension:0.630" Dia (16.00mm)
• Height - Seated (Max):0.689" (17.50mm)
• Surface Mount Land Size:0.673" L x 0.673" W (17.10mm x 17.10mm)
• Mounting Type:Surface Mount
• Package / Case:Radial, Can - SMD
