B41858D5478M9
TDK EPCOS
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 4700UF 20% 25V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet B41858D5478M9 Datasheet
-
ECAD Model
- Share
In Stock: 143
Can ship immediately
Pricing:
- 1$1.40734
- 3,000$1.27941
Quote It
Technical Details
- Series:B41858
- Package:Tape & Box (TB)
- Part Status:Active
- Capacitance:4700 µF
- Tolerance:±20%
- Voltage - Rated:25 V
- ESR (Equivalent Series Resistance):21mOhm @ 10kHz
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:Automotive
- Ripple Current @ Low Frequency:-
- Ripple Current @ High Frequency:3.539 A @ 100 kHz
- Impedance:20 mOhms
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.709" Dia (18.00mm)
- Height - Seated (Max):1.319" (33.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
