PDSE1-S5-S24-D

Technical Details

• Series:PDSE1-D (1W)
• Package:Tube
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:1
• Voltage - Input (Min):4.5V
• Voltage - Input (Max):5.5V
• Voltage - Output 1:24V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):42mA
• Power (Watts):1 W

• Voltage - Isolation:3 kV
• Applications:ITE (Commercial)
• Features:-
• Operating Temperature:-40°C ~ 105°C (With Derating)
• Efficiency:85%
• Mounting Type:Through Hole
• Package / Case:8-DIP Module, 4 Leads
• Size / Dimension:0.50" L x 0.40" W x 0.32" H (12.7mm x 10.2mm x 8.2mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:CB Scheme, EN, IEC, UL
• Standard Number:55024; 55032 Class A; 62368-1
