MGJ1D051505MPC-R7

Technical Details

• Series:MGJ1 (1W)
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:2
• Voltage - Input (Min):4.5V
• Voltage - Input (Max):5.5V
• Voltage - Output 1:15V
• Voltage - Output 2:-5V
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):50mA, 50mA
• Power (Watts):1 W

• Voltage - Isolation:5.2 kV
• Applications:ITE (Commercial), Medical
• Features:SCP
• Operating Temperature:-40°C ~ 105°C
• Efficiency:63.5%
• Mounting Type:Surface Mount
• Package / Case:8-SMD Module
• Size / Dimension:0.78" L x 0.59" W x 0.17" H (19.7mm x 15.0mm x 4.4mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:-
• Standard Number:-
