RS3-2405S
RECOM Power
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDC DC CONVERTER 5V 3W
- CategoryDC DC Converters
- Datasheet RS3-2405S Datasheet
-
ECAD Model
- Share
In Stock: 156
Can ship immediately
Pricing:
- 1$13.17
- 5$13.06496
- 22$12.96571
- 44$12.76601
- 66$12.36707
- 110$11.17026
- 264$10.97079
- 506$10.77132
Quote It
Technical Details
- Series:ECONOLINE RS3 (3W)
- Package:Tube
- Part Status:Active
- Type:Isolated Module
- Number of Outputs:1
- Voltage - Input (Min):18V
- Voltage - Input (Max):36V
- Voltage - Output 1:5V
- Voltage - Output 2:-
- Voltage - Output 3:-
- Voltage - Output 4:-
- Current - Output (Max):600mA
- Power (Watts):3 W
- Voltage - Isolation:1 kV
- Applications:ITE (Commercial)
- Features:Remote On/Off, SCP
- Operating Temperature:-40°C ~ 71°C
- Efficiency:81%
- Mounting Type:Through Hole
- Package / Case:8-SIP Module, 7 Leads
- Size / Dimension:0.86" L x 0.36" W x 0.44" H (21.8mm x 9.2mm x 11.1mm)
- Supplier Device Package:-
- Control Features:Enable, Active Low
- Approval Agency:-
- Standard Number:-
