SPU01M-15
MEAN WELL
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDC DC CONVERTER 15V 1W
- CategoryDC DC Converters
- Datasheet SPU01M-15 Datasheet
-
ECAD Model
- Share
In Stock: 107
Can ship immediately
Pricing:
- 1$3.03
- 10$2.94781
- 25$2.86087
- 50$2.77413
Quote It
Technical Details
- Series:SPU01 (1W)
- Package:Tube
- Part Status:Active
- Type:Isolated Module
- Number of Outputs:1
- Voltage - Input (Min):10.8V
- Voltage - Input (Max):13.2V
- Voltage - Output 1:15V
- Voltage - Output 2:-
- Voltage - Output 3:-
- Voltage - Output 4:-
- Current - Output (Max):67mA
- Power (Watts):1 W
- Voltage - Isolation:1.5 kV
- Applications:ITE (Commercial)
- Features:SCP
- Operating Temperature:-40°C ~ 90°C (With Derating)
- Efficiency:84%
- Mounting Type:Through Hole
- Package / Case:6-SIP Module, 5 Leads
- Size / Dimension:0.77" L x 0.24" W x 0.40" H (19.5mm x 6.1mm x 10.2mm)
- Supplier Device Package:-
- Control Features:-
- Approval Agency:-
- Standard Number:-
