ITU0324D12

Technical Details

• Series:ITU03 (3W)
• Package:Tube
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:2
• Voltage - Input (Min):9V
• Voltage - Input (Max):36V
• Voltage - Output 1:12V
• Voltage - Output 2:-12V
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):125mA, 125mA
• Power (Watts):3 W

• Voltage - Isolation:1.6 kV
• Applications:ITE (Commercial)
• Features:Remote On/Off
• Operating Temperature:-40°C ~ 80°C (With Derating)
• Efficiency:83%
• Mounting Type:Through Hole
• Package / Case:8-DIP Module, 6 Leads
• Size / Dimension:0.55" L x 0.55" W x 0.32" H (14.0mm x 14.0mm x 8.1mm)
• Supplier Device Package:-
• Control Features:Enable, Active Floating
• Approval Agency:-
• Standard Number:-
