PQDE6W-Q48-S3-D

Technical Details

• Series:PQDE6W-D (6W)
• Package:Tube
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:1
• Voltage - Input (Min):18V
• Voltage - Input (Max):75V
• Voltage - Output 1:3.3V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):1.5A
• Power (Watts):5 W

• Voltage - Isolation:1.5 kV
• Applications:ITE (Commercial)
• Features:OCP, OVP, SCP, UVLO
• Operating Temperature:-40°C ~ 85°C (With Derating)
• Efficiency:79%
• Mounting Type:Through Hole
• Package / Case:5-DIP Module, 4 Leads
• Size / Dimension:1.00" L x 1.00" W x 0.46" H (25.4mm x 25.4mm x 11.7mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:CB Scheme, EN, IEC, UL
• Standard Number:55024; 55032 Class A; 60950-1
