AM10T-2405DNZ

Technical Details

• Series:AM10T-NZ (10W)
• Package:Tube
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:2
• Voltage - Input (Min):18V
• Voltage - Input (Max):36V
• Voltage - Output 1:5V
• Voltage - Output 2:-5V
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):1A, 1A
• Power (Watts):10 W

• Voltage - Isolation:1.5 kV
• Applications:ITE (Commercial)
• Features:Remote On/Off
• Operating Temperature:-40°C ~ 65°C (With Derating)
• Efficiency:83%
• Mounting Type:Through Hole
• Package / Case:24-DIP Module, 9 Leads
• Size / Dimension:1.26" L x 10.78" W x 0.42" H (32.0mm x 20.0mm x 10.8mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:-
• Standard Number:-
