RP40-11024DFR/P-HC

Technical Details

• Series:POWERLINE RP40-FR (40W)
• Package:Tube
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:2
• Voltage - Input (Min):43V
• Voltage - Input (Max):160V
• Voltage - Output 1:24V
• Voltage - Output 2:-24V
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):833mA, 833mA
• Power (Watts):40 W

• Voltage - Isolation:3 kV
• Applications:ITE (Commercial), Railway
• Features:Remote On/Off, OCP, OTP, OVP, SCP, UVLO
• Operating Temperature:-40°C ~ 105°C (With Derating)
• Efficiency:91%
• Mounting Type:Through Hole
• Package / Case:6-DIP Module
• Size / Dimension:2.24" L x 1.00" W x 0.66" H (56.8mm x 25.4mm x 16.8mm)
• Supplier Device Package:6-DIP Module
• Control Features:Enable, Active High
• Approval Agency:-
• Standard Number:-
