AM200QB-4824SH22-NZ-M-192

Technical Details

• Series:AM200QB-NZ (200W)
• Package:Box
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:1
• Voltage - Input (Min):18V
• Voltage - Input (Max):75V
• Voltage - Output 1:24V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):8.4A
• Power (Watts):202 W

• Voltage - Isolation:2.25 kV
• Applications:ITE (Commercial)
• Features:Remote On/Off
• Operating Temperature:-40°C ~ 85°C (With Derating)
• Efficiency:91%
• Mounting Type:Through Hole
• Package / Case:Quarter Brick
• Size / Dimension:2.43" L x 2.20" W x 0.57" H (61.8mm x 56.0mm x 14.6mm)
• Supplier Device Package:Quarter Brick
• Control Features:-
• Approval Agency:-
• Standard Number:-
