QSB30048S28

Technical Details

• Series:QSB (300W)
• Package:Box
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:1
• Voltage - Input (Min):18V
• Voltage - Input (Max):75V
• Voltage - Output 1:28V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):10.7A
• Power (Watts):300 W

• Voltage - Isolation:1.5 kV
• Applications:ITE (Commercial)
• Features:Remote On/Off, OCP, OTP, OVP, SCP
• Operating Temperature:-40°C ~ 100°C
• Efficiency:88%
• Mounting Type:Through Hole
• Package / Case:9-DIP Module
• Size / Dimension:2.40" L x 2.28" W x 0.52" H (61.0mm x 57.9mm x 13.2mm)
• Supplier Device Package:-
• Control Features:Enable, Active High
• Approval Agency:-
• Standard Number:-
