TES 2-2422H

Technical Details

• Series:TES 2H (2W)
• Package:Tube
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:2
• Voltage - Input (Min):21.6V
• Voltage - Input (Max):26.4V
• Voltage - Output 1:12V
• Voltage - Output 2:-12V
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):83mA, 83mA
• Power (Watts):2 W

• Voltage - Isolation:1.5 kV
• Applications:ITE (Commercial)
• Features:SCP
• Operating Temperature:-40°C ~ 85°C (With Derating)
• Efficiency:79%
• Mounting Type:Surface Mount
• Package / Case:10-SMD Module, 6 Leads
• Size / Dimension:0.64" L x 0.37" W x 0.35" H (16.3mm x 9.3mm x 8.9mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:-
• Standard Number:-
