PKV3211PI

Technical Details

• Series:PKV 5000
• Package:Tray
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:1
• Voltage - Input (Min):9V
• Voltage - Input (Max):36V
• Voltage - Output 1:5V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):500mA
• Power (Watts):2.5 W

• Voltage - Isolation:1.5 kV
• Applications:ITE (Commercial)
• Features:-
• Operating Temperature:-40°C ~ 95°C (With Derating)
• Efficiency:82%
• Mounting Type:Through Hole
• Package / Case:24-DIP Module, 10 Leads
• Size / Dimension:1.25" L x 0.80" W x 0.42" H (31.8mm x 20.3mm x 10.7mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:CB, CSA, IEC, TUV, UL
• Standard Number:62368-1
