TEL 8-1213
TRACO Power
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDC DC CONVERTER 15V 8W
- CategoryDC DC Converters
- Datasheet TEL 8-1213 Datasheet
-
ECAD Model
- Share
In Stock: 127
Can ship immediately
Pricing:
- 1$20.2
- 10$20.2
Quote It
Technical Details
- Series:TEL 8 (8W)
- Package:Tube
- Part Status:Active
- Type:Isolated Module
- Number of Outputs:1
- Voltage - Input (Min):9V
- Voltage - Input (Max):18V
- Voltage - Output 1:15V
- Voltage - Output 2:-
- Voltage - Output 3:-
- Voltage - Output 4:-
- Current - Output (Max):535mA
- Power (Watts):8 W
- Voltage - Isolation:1.5 kV
- Applications:ITE (Commercial)
- Features:SCP
- Operating Temperature:-40°C ~ 80°C
- Efficiency:84%
- Mounting Type:Through Hole
- Package / Case:16-DIP Module, 6 Leads
- Size / Dimension:0.95" L x 0.55" W x 0.33" H (24.1mm x 14.0mm x 8.5mm)
- Supplier Device Package:-
- Control Features:-
- Approval Agency:-
- Standard Number:-
