EC2SBW-48D12N
Cincon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDC DC CONVERTER +/-12V 10W
- CategoryDC DC Converters
-
ECAD Model
- Share
In Stock: 116
Can ship immediately
Pricing:
- 1$27.33667
- 12$27.06583
Quote It
Technical Details
- Series:EC2SBW (10W)
- Package:Tube
- Part Status:Active
- Type:Isolated Module
- Number of Outputs:2
- Voltage - Input (Min):18V
- Voltage - Input (Max):75V
- Voltage - Output 1:12V
- Voltage - Output 2:-12V
- Voltage - Output 3:-
- Voltage - Output 4:-
- Current - Output (Max):416mA, 416mA
- Power (Watts):10 W
- Voltage - Isolation:1.5 kV
- Applications:ITE (Commercial)
- Features:Remote On/Off, OCP, OVP, SCP, UVLO
- Operating Temperature:-40°C ~ 85°C (With Derating)
- Efficiency:86%
- Mounting Type:Through Hole
- Package / Case:6-DIP Module
- Size / Dimension:1.00" L x 1.00" W x 0.40" H (25.4mm x 25.4mm x 10.2mm)
- Supplier Device Package:-
- Control Features:Enable, Active Low
- Approval Agency:-
- Standard Number:-
