NDM2Z-25HS-V-001

Technical Details

• Series:Novum® NDM2Z
• Package:Box
• Part Status:Not For New Designs
• Type:Non-Isolated PoL Module, Digital
• Number of Outputs:1
• Voltage - Input (Min):4.5V
• Voltage - Input (Max):14V
• Voltage - Output 1:0.6 ~ 3.3V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):25A
• Power (Watts):-

• Voltage - Isolation:-
• Applications:ITE (Commercial)
• Features:Digital
• Operating Temperature:-40°C ~ 125°C
• Efficiency:93.9%
• Mounting Type:Surface Mount
• Package / Case:15-SMD Module
• Size / Dimension:1.01" L x 0.54" W x 0.32" H (25.7mm x 13.8mm x 8.2mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:-
• Standard Number:-
