THL 20-4810WI
TRACO Power
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDC DC CONVERTER 3.3V 15W
- CategoryDC DC Converters
- Datasheet THL 20-4810WI Datasheet
-
ECAD Model
- Share
In Stock: 118
Can ship immediately
Pricing:
- 1$51.19
- 10$51.19
Quote It
Technical Details
- Series:THL 20WI (20W)
- Package:Tube
- Part Status:Not For New Designs
- Type:Isolated Module
- Number of Outputs:1
- Voltage - Input (Min):18V
- Voltage - Input (Max):75V
- Voltage - Output 1:3.3V
- Voltage - Output 2:-
- Voltage - Output 3:-
- Voltage - Output 4:-
- Current - Output (Max):4.5A
- Power (Watts):15 W
- Voltage - Isolation:1.5 kV
- Applications:ITE (Commercial)
- Features:Remote On/Off, SCP
- Operating Temperature:-40°C ~ 75°C (With Derating)
- Efficiency:88%
- Mounting Type:Through Hole
- Package / Case:6-DIP Module
- Size / Dimension:1.00" L x 1.00" W x 0.40" H (25.4mm x 25.4mm x 10.2mm)
- Supplier Device Package:-
- Control Features:-
- Approval Agency:-
- Standard Number:-
